Description:
Wall Mount Network Cabinet is ideal for areas that don't have enough equipment to require a full-size cabinet and protects computers, routers, modems, and other devices in a space-saving. Network Cabinet or 4U Network Cabinet adopts ventilated or removable panel design that allows generous airflow to keep equipment operating safely.
Configuration for standard racks is welded frame integrated with side panels and vented top cover with fan mounting provision, while the front glass with lock & key provides the visibility & security, rear side of the Rack is provided with the wall mounting slots for your equipment. In Wall Network Cabinet are available from 4U to 15U Variants with 400mm, 450mm, 500mm, and 600mm deep configuration.
MJADOM has a powerful OEM service that can undertake customized service according to your requirements.
Features:
Network Switch Cabinet Comply with DIN 41494 OR equivalent ISO Standards.
Home Network Cabinet Wall Mount adopts Welded frame, reliable structure.
Powder-coated finish with pretreatment process meeting all industry standards.
Floor-standing or wall-mount easy installation.
Optional adjustable feet and heavy-duty castors.
Removable side panels, optional side locks.
Top and bottom Panel with ventilation and cable entry facility.
Provision to mount cooling fans on the top panel.
4U Server Rack / Server Rack 4U; Fans, Ø 4.7" (120 mm).
The turning angle of the front door is over 180°.
Intended for installation of 19” standard equipment.
Locks securely to help prevent damage, tampering or theft.
Grounding and Bonding Options. 100% assured compatibility with all equipment conforming to DIN 41494 (General industrial standard for equipment).
Product Details:
| Rack Type | Network Cabinet | Style | Wall Mount |
| Color | Black / Grey | Dimensions (HxWxD) | 4U; 10.9"x23.6"x17.7" (279x600x450mm) |
| Factory Preset Rack Depth | 17.0'' (430 mm) | Weight Capacity - Stationary | 198.4lbs (90kg) |
| Material | Mounting profile: 1.5mm SPCC cold rolled steel construction;Others: 1.2mm SPCC cold rolled steel construction. | Rack Height | 4U / 6U / 9U / 12U / 15U or Customized |
| Mounting Rails | Square-Punched | Grounding Wire | Front and back door frames |
| Installation | Standard EIA 19" Rack Rails | Device Compatibility | Routers; Modems; Network Switch; UPS; Server. |
| Protection Level | IP20 | Included Accessories | 28 pieces each of 12-24 screws and washers |
Application:
Data application / IT Equipment.
Perfect for Private / enterprise networks.
Ideal for switches, servers, patch panels, or copper cabling solutions.
