Description:
Cat5e UTP network patch cable is the cost-effective solution for indoor data center applications, supporting up to 1000Mbps and 100MHz within 100 meters of cable. And Patch Cord Cat5e fully backward compatible with all the previous categories.
The Cat5e Patch Cords conductor applies Oxygen-free Copper with PVC CMX outer sheath, which is durable, flame-retardant, resistant to bending. Cat5e Patch Cable is the standard for next-generation twisted-pair cabling, enables up to four times faster data transfer on the same cabling type, and supports 1000Mbps within 100 meters applications. Cat5e cables are not only halogen-free and flame-retardant (LSOH), but also GHMT certified for quality and performance.
Cat5e Patch Cord UTP or Cat5e Patch Cord RJ45 complies with Cat5e patch panels.
Features:
Stranded Oxygen-free Copper design and Passed the Fluke Channel Test.
Cat5e cables in accordance with the EIA/TIA 568 standard.
Cable Type: Category 5e (Cat5e).
Transmission Speed: Up to 1000 Mbps.
Rated for 100MHz communications.
Connector Type: Unshielded gold plated RJ45(8P8C).
RJ45 Plug with 50µm gold-plated contacts.
Cable Conductor: Oxygen-free Copper 24-28AWG.
Cable Jacket: PVC CMX or LSOH Available.
GHMT Verified.
Product Details:
| Patch Cable Type | Cat5e | Wire Scheme | T568B, Straight |
| Patch Cable Jacket | PVC CMX | Length | 3m, 5m, 10 or customized |
| Conductor | RJ45 (Male) | Conductor Material | Oxygen-free Copper |
| Max Transmission Distance | 100m | PoE Compatibility | PoE/PoE+ |
| Gauge (AWG) | 24-28AWG | Cable Outer Diameter (mm) | 5.5± 0.4 |
| Data Rate Support | 10/100/1000Base-T | Standard Bandwidth | 100MHz |
| Shielding Type | Unshielded (UTP) | Standard | ISO/IEC 11801, ANSI/TIA-568.2-D |
| Operating Temperature | -20°C to +75°C (-4°F to 167°F) | Installation Temperature | -10°C to +50°C (14°F to 122°F) |
Application:
Rated for any 1000Base-T Ethernet.
Data applications (19" Rack & Cabinet).
Perfect for Private/enterprise networks.
Ideal for switches, servers, patch panels, or copper cabling solutions.
